| Attribute |
Comment |
Default / Example |
| Behavior |
| compatmode |
if set to "1" all TWiki:Plugins.CalendarPlugin event types are supported (related: compatmodeicon) |
compatmode="0" |
| daynames |
custom daynames (a list separated by a '¦' and starting on Monday; overwrites lang attribute) |
daynames="M¦T¦W¦T¦F¦S¦S" |
| days |
number of days to show |
days="30" |
| enablepubholidays |
enables/disables public holidays (bullet list entries with a @all in a person field; related: showpubholidays, pubholidayicon) |
enablepubholidays="1" |
| lang |
language (related: daynames, monthnames) |
lang="English" |
| month |
set a month (e.g. Jan, Feb ... or 01, 02, ... 12 ) or a month offset (e.g. +0, +1, -2,...) Note: If you use this month attribute the days attribute will be ignored (days will be set to the duration of the month). |
month="+1" |
| monthnames |
custom month names (a list separated by '¦' and starting on January; overwrites lang attribute) |
monthnames="J¦F¦M¦A¦M¦J¦J¦A¦S¦O¦N¦D" |
| namepos |
allows you to change the position of the names; allowed values: left, right, both |
namepos="left" |
| navdays |
defines the days to navigate to (default: value of the days attribute) |
navdays="30" |
| order |
changes the sorting order of entries and contains a comma separated list of names or special tags (default: alphanumerical order); hint: order attribute can also be used as a filter: show only listed persons (e.g. order="Bob,Bill"); specials: [:ralpha:] - sort persons reverse alphanumerical; [:nextfirst:] - next person with an entry will be shown first; [:rest:] - will be replaced by missing persons if order contains an uncomplete person list (e.g. order="Bob,Bill,[:rest:]"); [:num:] ([:rnum]) - (reverse) numerical order |
undefined / order="Bob,Bill,Alice,Jane,[:rest:]" |
| removeatwork |
set to "1" to remove persons without calendar entries from table |
removeatwork="0" |
| showmonthheader |
enabes/disables month header |
showmonthheader="1" |
| showoptions |
shows a navigation form |
showoptions="0" |
| showpubholidays |
shows public holidays as separate lines (rows) in table (related: enablepubholidays, pubholidayicon) |
showpubholidays="0" |
| showstatcol |
enables/disables statistics column(s) |
showstatcol="off" |
| showstatrow |
enables/disables statistics row(s) |
showstatrow="off" |
| showstatsum |
enables/disables statistics summary below/behind the statistics columns/rows; works only in conjunction with showstatcol and/or showstatrow |
showstatsum="on" |
| showweekends |
shows weekends if set to 1 |
showweekends="0" |
| startdate |
a start date (e.g. '1 Oct 2005') or a day offset (e.g. '10', '+30' or '-30') |
startdate="+0" |
| topic |
a comma separated list of source topics |
topic="%TOPIC%" |
| week |
set a week (1..52) or a week offset (-1, +0, +1, +2, ...) |
week="+0" |
| year |
set a year (e.g. 2005, 2006 ...) or a year offset (e.g. +0, +1, -1, ...) |
year="0" |
| Icons |
| adayofficon |
a day off icon |
adayofficon=":ok:" |
| compatmodeicon |
icon used for TWiki:Plugins.CalendarPlugin event types (only used if compatmode is enabled) |
compatmodeicon="8-)" |
| holidayicon |
holiday icon |
holidayicon="8-)" |
| notatworkicon |
not at work icon (only used if you type a location) |
notatworkicon=":-I" |
| pubholidayicon |
public holiday icon (related: enablepubholidays, showpubholidays) |
pubholidayicon=":-)" |
| workicon |
in work icon |
workicon=" " |
| Table Formatting |
| border |
table border |
border="1" |
| cellpadding |
table cell padding |
cellpadding="1" |
| cellspacing |
tabel cell spacing |
cellspacing="0" |
| daynames |
custom daynames (a list separated by a '¦' and starting on Monday; overwrites lang attribute) |
daynames="M¦T¦W¦T¦F¦S¦S" |
| headerformat |
table header format of a day; a subset of strftime conversion specifiers is supported (only date not time specificiers; see manual page or TWiki:Codev.ConvergeDateTimeFormattingModels) |
headerformat="<font size=\"-2\">%a<br/>%e</font>" |
| lang |
language (related: daynames, monthnames) |
lang="English" |
| maxheight |
maximum table height |
undefined / maxheight="200px" |
| monthheaderformat |
month header format (related: showmonthheader) |
monthheaderformat="%b" |
| monthnames |
custom month names (a list separated by '¦' and starting on January; overwrites lang attribute) |
monthnames="J¦F¦M¦A¦M¦J¦J¦A¦S¦O¦N¦D" |
| name |
header content of the first cell header |
name="Name" |
| namecolors |
a comma separated list of names with own colors, e.g. namecolors="Mary:red,Bob:lightblue" |
undefined / namecolors="Bill:yellow" |
| navdays |
defines the days to navigate to (default: value of the days attribute) |
navdays="30" |
| navenable |
enables/disables navigation (1 - enabled; 0 - disabled) |
navenable="1" |
| navhome |
navigation button to the start date (%d will be replaced with page x days) |
navhome="%d" |
| navhometitle |
title text (tooltip text) for the navigation button to the start date |
navhometitle="Go to the start date" |
| navnext |
navigation button to the next navdays days |
navnext=">¦" |
| navnexthalf |
navigation button to the next navdays/2 days |
navnexthalf=">" |
| navnexthalftitle |
title text (tooltip text) for the navigation button to the next navdays/2 days (%n will be replaced with the half number of days to show) |
navnexttitle="Next %n day(s)" |
| navnexttitle |
title text (tooltip text) for the navigation button to the next navdays days (%n will be replaced with the number of days to show) |
navnexttitle="Next %n day(s)" |
| navprev |
navigation button to the previous navdays days |
navprev="<br/>¦<" |
| navprevhalf |
navigation button to the previous navdays/2 days |
navprevhalf="<" |
| navprevhalftitle |
title text (tooltip text) for the navigation button to the previous navdays/2 days (%n will be replaced with the half number of days to show) |
navprevtitle="Previous %n day(s)" |
| navprevtitle |
title text (tooltip text) for the navigation button to the previous navdays days (%n will be replaced with the number of days to show) |
navprevtitle="Previous %n day(s)" |
| nwidth |
cell width of the first column |
nwidth="120px" |
| optionspos |
position of the navigation form; allowed values: top, bottom, both |
optionspos="bottom" |
| optionsformat |
defines the output format of the navigation form; some variables are available: %(WEEK|MONTH|YEAR)SEL(<range>) - a week|month|year popup menu; %(STARTDATE|WEEK|MONTH|YEAR)OFFS(<range>) - a day|week|month|year offset popup menu; %(STARTDATE|WEEK|MONTH|YEAR)(<default value>) - a startdate|week|month|year input field; %BUTTON(<submit button text>) - a submit button; ranges are optional (range syntax: <start value>(:<end value>(:<steps>)?)?, e.g. %YEARSEL(2002:2010:1) |
optionsformat="Month: %MONTHSEL, Year: %YEARSEL %BUTTON(Change)" |
| rowcolors |
a comma separated list of background colors used for entries; the color count is not limited |
rowcolors="#ffffff,#f0f0f0" |
| tablebgcolor |
table background color |
tablebgcolor="white" |
| tablecaption |
table caption |
tablecaption=" " |
| tablecaptionalign |
table caption alignment (top, bottom, left, right) |
tablecaptionalign="top" |
| tableheadercolor |
color of the table header |
tableheadercolor="%WEBBGCOLOR%" |
| tcwidth |
width of the icon table cells |
tcwidth="33px" |
| todaybgcolor |
background color for today cells (usefull if you use startdate attribute) |
todaybgcolor="white" |
| todayfgcolor |
foreground color for today cells (usefull for a dark todaybgcolor) |
todayfgcolor="black" |
| weekendbgcolor |
background color of weekend header and data table cells |
weekendbgcolor="%WEBBGCOLOR%" |
| width |
width of table in pixels or percent |
width="100%" |
Table Formatting - Statistics ( showstatcol or showstatrow should be enabled) |
| statcolformat |
statistics column format (related: showstatcol, statcolheader, statcoltitle); see Statistics Column/Row Format/Title section |
statcolformat="%{hh}" -or- statcolofrmat="%{h}" (if showweekends set to "on") |
| statcolheader |
statistics header (related: showstatcol, statcolformat, statcoltitle); use '|' to separate multiple column headers |
statcolheader="#" |
| statcoltitle |
statistics tooltip (related: showstatcol, statcolformat, statcolheader); see Statistics Column/Row Format/Title section |
statcoltitle="%{ll}" -or- statcoltitle="%{l}" (if showweekends set to "on") |
| statformat |
statistics format; overwrites statcolformat and statrowformat |
undefined / statformat="%{hh}" |
| statformat_0 |
defines the string for the zero value of all statistics variables; Statistics Column/Row Format/Title section |
statformat_0="0" |
| statformat_i |
format for a single %{i} variable value; %ICON will be substituted by the icon; see Statistics Column/Row Format/Title section |
statformat_i="%{i:%ICON} x %ICON ;" |
| statformat_ii |
format for a single %{ii} variable value; %ICON will be substituted by the icon; see Statistics Column/Row Format/Title section |
statformat_ii="%{ii:%ICON} x %ICON ;" |
| statformat_l |
format for a single %{l} variable value; %LOCATION will be substituted by the location; see Statistics Column/Row Format/Title section |
statformat_l="%{l:%LOCATION} x %LOCATION;" |
| statformat_ll |
format for a single %{ll} variable value; %LOCATION will be substituted by the location; see Statistics Column/Row Format/Title section |
statformat_ll="%{ll:%LOCATION} x %LOCATION;" |
| statformat_perc |
percentage format |
statformat_perc="%3.1f%%" |
| statformat_unknown |
will be used for unknown locations or icons if one of the statistics variables %{l}, %{ll}, %{i} or %{ii}) is replaced |
statformat_unknown="unknown" |
| statheader |
statistics header; overwrites statcolheader and statrowheader |
undefined / statheader="#" |
| statrowformat |
statistics row format (related: showstatrow, statrowheader, statrowtitle); see Statistics Column/Row Format/Title section |
statrowformat="%{hh}" -or- statrowformat="%{h}" (if showweekends set to "on") |
| statrowheader |
statistics header (related: showstatrow, statrowformat, statrowtitle); use '|' to separate multiple row headers |
statrowheader="#" |
| statrowtitle |
statistics tooltip (related: showstatrow, statrowformat, statrowheader); see Statistics Column/Row Format/Title section |
statrowtitle="%{ll}" -or- statrowtitle="%{l}" (if showweekends set to "on") |
| stattitle |
statistics tooltip; overwrites statrowtitle and statcoltitle |
undefined / stattitle="%{ll}" |
